·FANUC 0i-MF PLUS(5) system with 10.4″ color LCD monitor
·High strength cast iron bed
·Spindle directly connected to spindle motor via high-torque flexible coupling (up to 12,000 rpm)
·Rigid tapping
·24 robotic tool magazines
·Linear guides (X – 34mm, Y/Z – 45mm)
·Servo motors are directly connected to extra-large, double pre-tension screws (X – φ40 mm, Y – φ40 mm, Z – φ40 mm).
·Faster traverse speeds (X – 36 m/min, Y – 36 m/min, Z – 30 m/min)
·Accuracy (positioning accuracy 0.008/0.008/0.008, repeat positioning accuracy 0.005/0.005/0.005)
·FANUC 0i-MF PLUS (5) Digital Control System
·24 tool arm magazine
·12000rpm direct coupled spindle + spindle oil cooling unit
·Integral Shroud sliding door
·Screw chip conveyor and chip accumulator（When the chip is too long, the user increases the chip breaking operation, the length is less than 100mm）.
·Automatic lubrication system
·Tools & Toolboxes
·In-machine working light
·Three-color warning light for machine tools
· Electrical box heat exchanger
· Spindle air curtain dust protection system
· Spindle taper hole blowing device
· Rigid tapping
· Workpiece cooling system
· USB interface and DNC function
·Embedded Ethernet (RJ45) interface
· Door-opening protection (guards)
· Portable handheld units
·Portable chip blowing air gun For cleaning the table and workpieces
· Simple oil-water separator
·Foundation mounting accessories
·Randomized technical information
