·FANUC 0i-MF PLUS (5) Control System equipped with a 10.4-inch color LCD display
·High-strength cast iron bed
·Spindle driven by toothed belt transmission
·Rigid tapping
·24-tool robotic arm tool magazine
·Sliding guideways (X – 65 mm, Y – 130 mm, Z – 100 mm)
·Direct-drive connection between servo motors and oversized, double-preloaded ball screws (X – φ40 mm, Y – φ40 mm, Z – φ40 mm)
·Higher rapid traverse rate (X – 24 m/min, Y – 24 m/min, Z – 20 m/min)
·FANUC 0i-MF PLUS (5) CNC System
·24-tool Arm-type Tool Magazine
·8000rpm Belt-driven Spindle
·Integral Protective Cover (Internal Sliding Door)
·Spiral Chip Auger and Chip Cart (Users shall perform chip breaking operation when chips are overlong; chip length ≤ 100mm)
·Automatic Lubrication System
·Tools and Toolbox
·Internal Machine Work Light
·Machine Three-color Warning Light
·Electrical Cabinet Heat Exchanger
·Spindle Air Curtain Dust-proof System
·Spindle Taper Hole Air-blow Device
·Rigid Tapping
·Workpiece Cooling System
·USB Interface and DNC Function
·Built-in Ethernet (RJ45) Interface
·Door Opening Protection Device (Protective Door)
·Portable Handheld Unit
·Handheld Chip-blowing Air Gun (For cleaning worktable and workpieces)
·Simple Oil-water Separator
·Foundation Installation Accessories
