·FANUC 0i- MF PLUS ( 1 ) system with 10.4″ color LCD monitor
·High strength cast iron bed
·Main shaft toothed belt transmission, optional: two-stage variable speed gear transmission
·Rigid tapping
·24 manipulator tool magazines
·Slide guide ( X – 100 mm, Y – 150 mm, Z – 100 mm)
·The ball screw and servo motor are directly connected with a flexible coupling, which has high efficiency and small backlash; the three-axis ball screw (X – φ50 mm, Y – φ50 mm, Z – φ50 mm) can be pre-stretched. Reduce the temperature rise and elongation to ensure the positioning accuracy and repeated positioning accuracy of the machine tool
·Faster rapid traverse ( X – 15 m/min, Y – 15 m/min, Z – 12 m/min)
·FANUC 0i-MF PLUS (1) CNC System
·24-tool Arm-type Tool Magazine
·24-tool Arm-type Tool Magazine
·8000rpm Belt-driven Spindle
·Integral Protective Cover (Internal Sliding Door)
·Spiral Chip Auger and Chip Cart (Users shall perform chip breaking operation when chips are overlong; chip length ≤ 100mm)
·Automatic Lubrication System
·Tools and Toolbox
·Internal Machine Work Light
·Machine Three-color Warning Light
·Electrical Cabinet Heat Exchanger
·Spindle Air Curtain Dust-proof System
·Spindle Taper Hole Air-blow Device
·Rigid Tapping
·Workpiece Cooling System
·USB Interface and DNC Function
·Built-in Ethernet (RJ45) Interface
·Door Opening Protection Device (Protective Door)
·Portable Handheld Unit
·Handheld Chip-blowing Air Gun (For cleaning worktable and workpieces)
·Simple Oil-water Separator
·Foundation Installation Accessories
·Random Technical Documents
