·FANUC 0i-MF PLUS (1) Control System equipped with a 10.4-inch color LCD display
·High-strength cast iron bed
·Spindle with toothed belt transmission; Optional: Two-speed gear transmission
·Rigid tapping
·24-tool robotic arm tool magazine
·Sliding guideways (X – 100 mm, Y – 150 mm, Z – 100 mm)
·Ball screws are directly connected to servo motors via flexible couplings, featuring high efficiency and small backlash; The three-axis ball screws (Xφ50 mm, Y – φ50 mm, Z – φ50 mm) can be pre-tensioned to reduce temperature rise elongation, ensuring the machine’s positioning accuracy and repeatability accuracy
·Higher rapid traverse rate (X – 15 m/min, Y – 15 m/min, Z – 12 m/min)
·FANUC 0i-MF PLUS (5) CNC System
·24-tool Arm-type Tool Magazine
·8000rpm Belt-driven Spindle
·Integral Protective Cover (Internal Sliding Door)
·Spiral Chip Auger and Chip Cart (Users shall perform chip breaking operation when chips are overlong; chip length ≤ 100mm)
·Automatic Lubrication System
·Tools and Toolbox
·Internal Machine Work Light
·Machine Three-color Warning Light
·Electrical Cabinet Heat Exchanger
·Spindle Air Curtain Dust-proof System
·Spindle Taper Hole Air-blow Device
·Rigid Tapping
·Workpiece Cooling System
·USB Interface and DNC Function
·Built-in Ethernet (RJ45) Interface
·Door Opening Protection Device (Protective Door)
·Portable Handheld Unit
·Handheld Chip-blowing Air Gun (For cleaning worktable and workpieces)
·Simple Oil-water Separator
·Foundation Installation Accessories
·Random Technical Documents
